XL Hydraulic Detachable Extendable Information
XL’s Hydraulic Detachable Extendables (HDE) are extendable lowboy trailers featuring our Classic Hydraulic Gooseneck. This commercial style gooseneck is robust and versatile, offering seven ride height positions. The HDE comes with a decked over wheel area for additional storage space. The hydraulic detachable gooseneck comes apart from the main deck efficiently, using the truck’s wet kit or a motor to allow loading from the front. The XL Hydraulic Detachable Extendable (HDE) features the patented XL Extend-A-Trac, which allows for extending and retracting the trailer without hooking and unhooking air and electrical lines, and a patent-pending main deck design. Enjoy user-friendly standard features such as chain drops, swingout outrigger brackets, and an improved track design. This versatile, extendable lowboy is sure to fit your hauling needs.
Model | XL 70 HDE | XL 70 HDEM | XL 80 HDE | XL 80 HDEM | XL 90 HDE | XL 90 HDEM | XL 100 HDE | XL 110 HDE | XL 110 HDEM | XL 120 HDE | XL 130 HDE | XL 140 HDE |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Capacity | 70,000 lbs | 70,000 lbs | 80,000 lbs | 80,000 lbs | 90,000 lbs | 90,000 lbs | 100,000 bs | 110,000 lbs | 110,000 lbs | 120,000 lbs | 130,000 lbs | 140,000 lbs |
Concentrated Capacity |
50,000 lbs in 10′ closed | 70,000 lbs in 16′ closed | 60,000 lbs in 10′ closed | 80,000 lbs in 16′ closed | 70,000 lbs in 10′ closed | 90,000 lbs in 16′ closed | 80,000 lbs in 10′ closed | 90,000 lbs in 10′ closed | 110,000 lbs in 16′ closed | 100,000 lbs in 10′ closed | 110,000 lbs in 10′ closed | 120,000 lbs in 10′ closed |
Gooseneck Length | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 10′ 5″ | 12′ 5″ | 12′ 5″ | 13′ 8″ |
Standard Main Deck Length Range |
28′ 7″ – 49′ 11″ | 28′ 3″ – 49′ 8″ | 28′ 7″ – 49′ 11″ | 28′ 3″ – 49′ 8″ | 28′ 7″ – 49′ 11″ | 28′ 3″ – 49′ 8″ | 28′ 7″ – 49′ 11″ | 24′ 1″ – 40′ 11″ | 27′ 7″ – 48′ 3″ | 27′ 1″ – 46′ 11″ | 27′ 1″ – 46′ 11″ | 24′ 1″ – 40′ 11″ |
Loaded Deck Height | 20″ | 14″ | 20″ | 14″ | 20″ | 14″ | 20″ | 24″ | 15″ | 24″ | 24″ | 24″ |
Ground Clearance | 6″ | 4″ | 6″ | 4″ | 6″ | 4″ | 6″ | 6″ | 4″ | 6″ | 6″ | 6″ |
Standard Axles | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 |
Standard OAL | 48′ Closed | 48′ | 48′ Closed | 48′ Closed | 48′ Closed | 48′ | 48′ Closed | 48′ Closed | 53′ Closed | 53′ Closed | 53′ Closed | 51′ 3″ Closed |
Wheel Area | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered | Wood-covered |
Engine
Performance
List of Features
Manufacturer | XL Trailers |
Category | Trailers |
Subcategory | Extendable Trailers |
Condition | New |
Hours | 0 |
